Elastomer Rings TSCHANS TNR

0₫

TNR - 120.1

TNR - 160.2

TNR - 160.1

TNR - 200.2

TNR - 200.1

TNR - 260.2

TNR - 260.1

TNR - 320.2

100% genuine product

Dedicated 24/7 shopping advice. Hotline: +84906 955 057

Free shipping for orders over 499,000 VND

Key Characteristics of the Elastomer TSCHANS TNR

Genuine TSCHANS TNR Elastomer Rings (TNR Buffer) come in a variety of types and sizes. This genuine elastomer ring is used for Ringfeder TNR couplings and is widely used in industries.

Elastomer Rings TNR are manufactured by Ringfeder/Germany. It also known as "vòng đệm giảm chấn TNR".

- The TNR 2424.1 features a high-spiral pipe, single row, size 260, with a spacer Pb 70 and flange connection SAE size 16, center bore diameter 100 H7 with keyway according to DIN 6885/1 P9 and set screw.

- The TNR 2424.2, size 260,2 – 16, includes a high-spiral pipe, double row, size 260, spacers Pb 70 inside and Pb 60 outside, with flange connection SAE size 16, center bore diameter 80 H7 with keyway to DIN 6885/1 P9 and set screw.

- The TNR 2425.2, size 260,2 – 11,5, comprises a high-spiral tube, double row, size 260, Vk 90 inner and Vk 80 outer gaskets, SAE flange connection-size 11,5, with 2517 cone locking bushings and 48-hole tube dome.

- The TNR 2428.1, size 260,1, has a spiral tube, single row, size 260, Vk 90 spacer, center bore diameter 100 H7 with keyway to DIN 6885/1 P9, flange screw with bore diameter 120 H7, keyway to DIN 6885/1 P9, and set screw.

Product Specifications of Elastomer TSCHANS TNR

TSCHANS TNR Catalogue	TSCHANS TNR Installation Instruction

Coupling Model	Buffer inside/ outside	Nominal torque	Max. torque	Permanent oscillating torque	Max speed
Coupling Model	Buffer inside/ outside	T_KN [Nm]	T_kmax[Nm]	T_KW [Nm]	1/min
TNR - 120.1 TNR - 160.2	Pb 60 Pb60 / Pb60	160	320	96	6000 5000
TNR - 120.1 TNR - 160.2	Pb 70 Pb70 / Pb60	180	360	108	6000 5000
TNR - 120.1 TNR - 160.2	Pb 80 Pb 80 / Pb 70	300	600	180	6000 5000
TNR - 120.1 TNR - 160.2	VK 80 VK 80 / Vk 80	300	600	180	6000 5000
TNR - 120.1 TNR - 160.2	VK 90 VK 90 / Vk 80	510	1020	306	6000 5000
TNR - 160.1 TNR - 200.2	Pb 60 Pb 60 / Pb 60	325	650	195	5000 4000
TNR - 160.1 TNR - 200.2	Pb 70 Pb70 / Pb60	360	720	216	5000 4000
TNR - 160.1 TNR - 200.2	Pb 80 Pb 80 / Pb 70	600	1200	360	5000 4000
TNR - 160.1 TNR - 200.2	VK 80 VK 80 / Vk 80	600	1200	360	5000 4000
TNR - 160.1 TNR - 200.2	VK 90 VK 90 / Vk 90	1020	2040	612	5000 4000
TNR - 200.1 TNR - 260.2	Pb 60 Pb 60 / Pb 60	675	1350	405	4000 3600
TNR - 200.1 TNR - 260.2	Pb 70 Pb70 / Pb60	750	1500	450	4000 3600
TNR - 200.1 TNR - 260.2	Pb 80 Pb 80 / Pb 70	1250	2500	750	4000 3600
TNR - 200.1 TNR - 260.2	VK 80 VK 80 / Vk 80	1250	2500	750	4000 3600
TNR - 200.1 TNR - 260.2	VK 90 VK 90 / Vk 80	2125	4250	1275	4000 3600
TNR - 260.1 TNR - 320.2	Pb 60 Pb 60 / Pb 60	1350	2700	810	3600 3000
TNR - 260.1 TNR - 320.2	Pb 70 Pb70 / Pb60	1500	3000	900	3600 3000
TNR - 260.1 TNR - 320.2	Pb 80 Pb 80 / Pb 70	2500	5000	1500	3600 3000
TNR - 260.1 TNR - 320.2	VK 80 VK 80 / Vk 80	2500	5000	1500	3600 3000
TNR - 260.1 TNR - 320.2	VK 90 VK 90 / Vk 80	4250	8500	2550	3600 3000

Why Choose Ringfeder Elastomer TSCHANS TNR?

Elastomer Rings TNR are essential components for Ringfeder TNR couplings. They are widely utilized in various power generation sectors, including wind and hydroelectric power plants. These rings also find applications in emergency power units and mobile generators.

Additionally, they are used in pumps and compressors, ensuring efficient and reliable performance. The versatility and durability of Elastomer Rings TNR make them indispensable in these industries. Their robust design helps in maintaining smooth operations across different power generation and machinery applications.
