Key Characteristics of the Elastomer Rings Gerwah GWE

The Elastomer Rings Gerwah GWE are capable of damping vibrations, torques from 3 to 560 Nm and are highly insulating, have low mass and even weight distribution – thanks to specially optimized hubs made of high-quality aluminium. It also known as "vòng đệm giảm chấn Gerwah GWE".

- Gerwah GWE is manufactured by Ringfeder in Germany, are known for their high quality and reliability.

- It is available in seven different sizes, offering flexibility to meet various application needs.

- The bore diameter ranges from 4 mm to 56 mm (0.157 to 2.205 inches), ensuring compatibility with a wide array of shafts.

- Additionally, the outside diameter varies from 24.5 mm to 94.5 mm (0.966 to 3.270 inches), providing a broad selection for diverse engineering requirements.

- Their robust design and precise dimensions make them suitable for demanding industrial applications, ensuring consistent performance and longevity.

Product Specifications of Elastomer Rings Gerwah GWE

Gerwah GWE Catalogue	Gerwah GWE Installation Instruction

Shore	Colour	Material	Continous temperature	Max. temp. short term	Available for size couplings
80 SH A	blue	Polyurethane	-50 to + 80℃	-60 to + 120℃	5 - 19
92 SH A	yellow	Polyurethane	-40 to + 90℃	-50 to + 120℃	5 - 55
*95/98 SH A	red	Polyurethane	-30 to + 90℃	-40 to + 120℃	5 - 75
64 SH D-H	green	Hytrel	-50 to +120℃	-60 to + 150℃	7 - 38
64 SH D	green	Polyurethane	-20 to +110℃	-30 to + 120℃	42 - 75

Coupling Size	SH	nmax [1/min]					Torque [Nm]
		5102	5113	5103.1	5104	5112	TN	Tmax
GWE - 5	80 Sh A	47500	---	38000	---	---	0.3	0.6
	92 Sh A						0.5	1
	98 Sh A						0.9	1.7
GWE - 7	64 Sh D-H	34000	---	27000	---	---	2.4	4.8
	80 Sh A						0.7	1.4
	92 Sh A						1.2	2.4
	98 Sh A						2	4
GWE - 9	64 Sh D-H	24000	---	19000	---	---	6	12
	80 Sh A						1.8	3.6
	92 Sh A						3	6
	98 Sh A						5	10
GWE - 12	64 Sh D-H	19000	15000	---	15000	---	12	24
	80 Sh A						3	6
	92 Sh A						5	10
	98 Sh A						9	18
GWE - 14	64 Sh D-H	16000	13000	---	13000	25400	16	32
	80 Sh A						4	8
	92 Sh A						7.5	15
	98 Sh A						12.5	25
GWE - 19	64 Sh D-H	12000	10000	---	10000	19000	21	42
	80 Sh A						5	10
	92 Sh A						10	20
	98 Sh A						17	34
GWE - 24	64 Sh D-H	8500	7000	---	7000	13800	75	150
	92 Sh A						35	70
	98 Sh A						60	120
GWE - 28	64 Sh D-H	7300	6000	7300	6000	11700	200	400
	92 Sh A						95	190
	98 Sh A						160	320
GWE - 38	64 Sh D-H	5900	5000	5900	5000	9550	405	810
	92 Sh A						190	380
	98 Sh A						325	650
GWE - 42	64 Sh D	---	4000	---	4000	8050	560	1120
	92 Sh A						265	530
	98 Sh A						450	900
GWE - 48	64 Sh D	---	---	---	3600	7200	655	1310
	92 Sh A						310	620
	98 Sh A						525	1050
GWE - 55	64 Sh D	---	---	---	3150	---	825	1650
	92 Sh A						410	820
	98 Sh A						685	1370
GWE - 65	64 Sh D	---	---	---	2800	---	1175	2350
	98 Sh A						940	1880
GWE - 75	64 Sh D	---	---	---	2350	---	2400	4800
	98 Sh A						1920	3840

Why Choose Ringfeder Elastomer Rings Gerwah GWE?

Ringfeder Elastomer Rings Gerwah GWE are manufactured in Germany and are renowned for their high quality and durability. These rings find widespread use in applications such as servo motors, precision drives, grinding and milling machines, packaging machines, woodworking equipment, and conveyor systems. With mandatory laser marking, they are easily identifiable, simplifying maintenance and ensuring the use of genuine parts.

In addition to their versatility, these elastomer rings are compatible with various joints, including GWE 5102, GWE 5103.1, GWE 5104, GWE 5106, GWE 5111, GWE 5113, GWE 5117, GWE Z5104.1, and GWE Z5106.1. Available in numerous sizes, they can meet specific needs and provide optimal performance in diverse setups, ensuring reliability across different industries.
